Description
Specification:
Brand: Geprc
Model: LC75 V3
Size: 7.5 inch
Wheelbase: 342mm
Top plate: 2.5mm
Bottom plate: 3.0mm
Arm plate: 6.0mm
FC mounting hole: 30.5mm*30.5mm
VTX mounting hole:20mm*20mm / 25.5mm*25.5mm
Motor mounting hole: 16mm*16mm / 19mm*19mm
Camera mounting hole: 19mm / 20mm
Recommended propeller size: 7-7.5inch
Weight: 266g
Feature:
Adopt a novel appearance design, strengthen the fuselage structure, and reduce the impact of fuselage vibration on the gyroscope sampling data.
The fuselage adds protective side panels for a more technological appearance and to protect the electronic control system from sand and dust pollution.
The integrated design of the battery plug and the body simplifies the power-on operation, simplicity and beauty.
Perfect match for 7-inch or 7.5-inch propellers
The Crocodile75 V3 frame has a lengthier fuselage, can be mounted with Lipo 6S 3300mah-4500mah or Lion 6S 6000mah battery for flight.
Package Includes:
Carbon plate list:
1 x GEP-LC75 V3 top plate
1 x GEP-LC75 V3 bottom plate
4 x GEP-LC75 V3 arms plate
1 x GEP-LC75 V3 front splint plate
1 x GEP-LC75 V3 front splint plate
Accessories:
1 x Header printed parts
1 x Tail printed parts
1 x GP camera base
4 x Motor damping pad
1 x Nylon front side plate (Pair)
1 x Nylon Rear side plate (Pair)(for DJI O3 version)
1 x Nylon Rear side plate (Pair) (universal version)
1 x XT60EW-M plug
2 x Rubber elastic anti-slip straps 20*250mm
4 x Motor wire hub 60mm*10mm
Screw kits:
4 x M3*5*30 mesh aluminum columns
4 x M3*5*21.5 mesh aluminum columns
10 x M3 Countersunk head Gaskets – wine red
6 x M3 pressed Rivet nuts
8 x M3*8 shock absorbing balls
10 x countersunk hexagon socket screws M3*8
4 x countersunk hexagon socket screws M3*12
4 x Hexagon socket screws with semicircular head M3*8
16 x Hexagon socket screws with semi-round head M3*11
8 x semi-round head hexagon socket screws M3*16
4 x countersunk hexagon socket screws M3*16
4 x Hexagon socket screws with semi-round head M3*25
6 x M3 aluminum alloy hexagonal lock nuts
2 x Hexagon socket screws with half round head M2*6
4 x round head hex socket screws with pad M2*4
4 xSilicone gasket for DJI O3 Air Unit
6 x Cup-head hex socket screws M1.6*12
4 x Hexagon socket screws with half round head M2*23
4 x Self-tightening nuts M2
4 x Nylon columns M2*5
4 x Hexagon socket screws with half round head _ Black Nickel plated M2*7
4 x M2 Nylon nuts
8 x Hexagon socket screws with semicircular head M3*6
4 x black mesh M3*13 aluminum columns
