Description
Features:
1. The OGS-50W comes with a built-in TX/RX auto cut circuit that automatically switches to transmit mode upon signal input. This eliminates the need for a special PTT line, enhancing the convenience of use.
2. This device is equipped with a powerful fan that turns on automatically to cool the unit when the temperature reaches the set value, thereby ensuring optimal performance and longevity.
3. With an operating frequency range of 3~24Mhz, it provides flexibility and adaptability to the user.
4. The OGS-50W has a high output power of 50W, ensuring effective signal transmission and greater communication range.
5. The unit operates at a voltage of 13.8V, making it energy-efficient and cost-effective.
Specifications:
- Operating Frequency: 3~24Mhz
- Transmit and Pull Power: 1～5W
- Output Power: 50W
- Interface Impedance: 50Ω
- Operating Voltage: 13.8V
Attention:
Before use, determine the transmitting antenna impedance of 50Ω, SWR < 1.5 using nanoVNA or similar tools. Failing to match the transmitting impedance can damage the power transmitter tube!
Package Included:
Type A: BNC Connector Type
1 x OGS-50W
1 x Power Cord
Type B: M Connector Type
1 x OGS-50W
1 x Power Cord
